SPECS
PROCESSOR
5th generation Intel Core i7-5557U processor
(3.1 GHz up to 3.4 GHz, Intel Turbo Boost Technology, dual-core, 4MB cache, 28W thermal design power (TDP))
MEMORY
Dual Channel DDR3L SODIMMs
1.3V, 1333/1600 MHz, 16GB maximum
GRAPHICS
Iris graphics 6100
1x mini HDMI* 1.4a
1x mini DisplayPort* 1.2
AUDIO
Up to 7.1 surround audio via mini HDMI and mini DisplayPort
headphone and microphone jack on the front panel
PERIPHERAL CONNECTIVITY
2x USB 3.0 ports on the back panel
2x USB 3.0 ports on the front panel (1x charging capable)
2x internal USB 2.0 via header
Consumer infrared sensor on the front panel
STORAGE
Internal support for M.2 SSD card (22x42, 22x60, or 22x80)
Internal SATA3 support for 2.5-inch HDD/SSD (up to 9.5 mm thickness)
NETWORKING
Intel PRO 10/100/1000 Network Connection
Intel Wireless AC 7265 M.2 soldered-down, wireless antennas (IEEE 802.11ac,Bluetooth*4,Intel Wireless Display)
ENCLOSURE
Silver with black top and diamond cut around the top
Aluminum and plastic, dimensions: 115 mm x 111 mm x 48.7 mm
POWER ADAPTER
19 V, 66W wall-mount AC-DC power adapter
Multi-country plugs (IEC types A/C/G/I)
ADDITIONAL FEATURES
Support for user-replaceable 3rd party lids
NFC and AUX_PWR headers
OS certs: Windows*7 and 8.1 logo'd
OS compatibility: Linux*
VESA mount bracket and mounting hole support
Low-acoustics active cooling design
Kensington*lock support
Integration guide
12-19 V DC power input
Power sensing circuit for protection against over-power shutdowns
3-year limited warranty
