Until recently, system integrators and OEMs had no choice but to limit their thinner, fully functional
computing designs to high-end devices. The available hard drive options were either too costly,
too slow performing or both.
Enter Seagate ingenuity. Momentus® Thin hard drives leverage current laptop drives in both material and
product design to provide the worlds first 7mm 2.5-inch form factor drive.
The result is affordable, thin storage for entry-level to mainstream laptops, high-end netbooks,
thin ultraportables and more. Momentus Thin drives open new frontiers in slim-computing design.
Seagate® SmartAlign technology for easy 4K migration.
moving from 512 to 4,096 bytes. The new format, known as Advanced Format (AF) 4K, offers advantages
like increased efficiency, but migrating your drive can be challenging.
Luckily, Seagate is ready to help you make a seamless transition to 4K sectors.
Momentus Thin hard drives feature Seagate SmartAlign technology, which automatically does the work
of AF migration in the background. The drive's performance is not affected, and there is no need for
time-consuming utilities required by other AF-enabled drives.
Smart.
Optimal security with Self-Encrypting Drives.
Momentus Thin hard drives are available as Self-Encrypting Drives (SED) that help secure your data the
instant you save it to your drive. For government-grade security, the Momentus Thin hard drive can also
be purchased as a FIPS 140-2 Validated SED.1
Lost laptop? Rest easy knowing that your data is secure and 100% encryptedalways. Momentus Thin hard
drive features include:
Instant on-the-fly encryption without performance degradation
Instant SecureErase technology that can instantly erase the security key data on your hard drive,
enabling secure and easy disposal or repurposing of the drive
TECH SPECS
Capactiy : 500GB
Form Factor : 2.5"
Interface Options : SATA 3Gb/s
Performance
Spindle Speed (RPM) : 5400
Cache (MB) : 16
Transfer Rate, : 600
Max Ext (MB/s)
Sustained Data Rate OD
Average Latency (ms) : 5.6
Power Management
Seek, Typical Operating (W) : 1.40
Idle, Typical Operating (W) : 0.45
Environmental
Temperature
Operating : 0° to 60°C
Non-operating : -40° to 70°C
Shock
Operating: Gs (ms) : 400 (2ms)
Non-operating: Gs (ms) : 1000 (1ms)
Acoustics (bels - sound power)
Idle : 2.0
Operating : 2.2
Physical
Height (in/mm) : 0.276/7.0
Width (in/mm) : 2.760/70.10
Length (in/mm) : 3.959/100.55
Weight (lb/g) : 0.209/95
