Specifications |
 |
Type of Camera
|
Compact digital still camera with built-in flash, 10x Optical/4x Digital/40x Combined Zoom with Optical Image Stabilizer (IS) System
|
Type
|
7.1 Megapixel, 1/2.5 inch type Charge Coupled Device (CCD)
|
Total Pixels
|
Approx. 7.4 Megapixels
|
Effective Pixels
|
Approx. 7.1 Megapixels
|
Focal Length
|
6.5-65.0mm f/3.5-5.6 (35mm film equivalent: 39-390mm)
|
Digital Zoom
|
4x
|
Focusing Range
|
Normal: 1.6 ft./50cm-infinity (WIDE), 3.3 ft./1.0m-infinity (TELE)
Macro: 3.9 in.-1.6 ft./10-50cm (WIDE)
Super Macro: 0-3.9 in./10cm (WIDE)
|
Autofocus System
|
TTL Autofocus
|
Viewfinder
|
N/A
|
LCD Monitor
|
1.8 inch low-temperature polycrystalline silicon TFT color LCD (vari-angle)
Brightness adjustment: 15 levels
|
LCD Pixels
|
Approx. 115,000 pixels
|
LCD Coverage
|
100%
|
Maximum Aperture
|
f/3.5 (W) - f/5.6 (T)
|
Shutter Speed
|
15-1/2500 sec.; Long Shutter operates with noise reduction when manually set at 1.3-15 sec.
|
ISO Sensitivity
|
Auto, High ISO Auto, ISO 80/100/200/400/800/1600 equivalent (Standard Output Sensitivity. Recommended Exposure Index)
|
Light Metering Method
|
Evaluative*, Center-weighted average, Spot**
* Control to incorporate facial brightness in Face Detection
AF
** Metering frame is fixed to the center
|
Exposure Control Method
|
Program AE; AE Lock is available
|
Exposure Compensation
|
+/-2 stops in 1/3-stop increments
|
White Balance Control
|
Auto, Preset (Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H), Custom
|
Built-in Flash
|
Auto, Auto w/ Red-eye Reduction, Auto w/ Slow Synchro, Flash On, Flash On w/ Red-eye Reduction, Flash On w/ Slow Synchro, Flash Off
|
Flash Range
|
Normal: 1.6-6.6 ft./50cm - 2.0m (W), 3.3-3.9 ft./1.0-1.2m (T)
Macro: 1.1-1.6 ft./35-50cm (W) (when sensitivity is set to ISO Auto)
|
Recycling Time
|
20 sec. or less (battery voltage=3.7V)
|
Flash Exposure Compensation
|
N/A
|
Shooting Modes
|
Auto, Camera M, Special Scene (Portrait, Foliage, Snow, Beach, Aquarium, Indoor, Night Snapshot), Color Accent, Color Swap, Super Macro, Stitch Assist, Movie
|
Self-Timer
|
Activates shutter after an approx. 2-sec./10-sec. delay, Custom
|
Wireless Control
|
N/A
|
Continuous Shooting
|
Normal: Approx. 2.2 fps
AF: Approx. 1.1 fps
|
Storage Media
|
SD Memory Card, SDHC Memory Card, MultiMediaCard, MMC Plus Card
|
File Format
|
Design rule for camera file system, DPOF Version 1.1
|
JPEG Compression Mode
|
Still Image: Exif 2.2 (JPEG)
Movie: AVI (Image: Motion JPEG; Audio: WAVE (Stereo))
|
Number of Recording Pixels
|
Still Image: 640 x 480 (Small), 1,600 x 1,200 (Medium 3), 2,048 x 1,536 (Medium 2), 2,592 x 1,944 (Medium 1), 3,072 x 2,304 (Large), 3,072 x 1,728 (Widescreen)
Movie: 1280 x 720/640 x 480 (30 fps/30 fps LP), 320 x 240 (60 fps/30 fps) available up to 4GB or 1 hour for each file size.
|
|
| |
Small/N |
Small/F |
Small/SF |
Medium3/N |
Medium3/F |
Medium3/SF |
Medium2/N |
| File Size |
84KB |
150KB |
249KB |
278KB |
558KB |
1,002KB |
445KB |
| 32MB MMC Plus |
278 |
177 |
114 |
102 |
53 |
30 |
66 |
| SDC-128M |
1,118 |
711 |
460 |
411 |
217 |
121 |
269 |
| SDC-512MSH |
4,317 |
2,747 |
1,777 |
1,590 |
839 |
471 |
1,041 |
| |
Medium2/F |
Medium2/SF |
Medium1/N |
Medium1/F |
Medium1/SF |
Large/N |
Large/F |
| File Size |
893KB |
1,602KB |
695KB |
1,395KB |
2,503KB |
902KB |
1,897KB |
| 32MB MMC Plus |
33 |
18 |
42 |
21 |
11 |
33 |
15 |
| SDC-128M |
136 |
76 |
173 |
87 |
49 |
134 |
64 |
| SDC-512MSH |
529 |
295 |
671 |
339 |
190 |
520 |
251 |
| |
Large/SF |
Widescreen/N |
Widescreen/F |
Widescreen/SF |
| File Size |
3,045KB |
678KB |
1,420KB |
2,304KB |
| 32MB MMC Plus |
9 |
43 |
21 |
12 |
| SDC-128M |
40 |
177 |
86 |
53 |
| SDC-512MSH |
156 |
686 |
335 |
207 | |
|
| |
1280x720* |
640x480 |
320x240 |
| |
30 fps |
30 fps LP |
30 fps |
30 fps LP |
60 fps |
30 fps |
| File Size |
4,480KB/sec. |
2,280KB/sec. |
1,920KB/sec. |
1,020KB/sec. |
1,370KB/sec. |
746KB |
| 32MB MMC Plus |
6 sec. |
12 sec. |
14 sec. |
26 sec. |
20 sec. |
35 sec. |
| SDC-128M |
26 sec. |
50 sec. |
58 sec. |
1 min. 48 sec. |
1 min. 21 sec. |
2 min. 24 sec. |
| SDC-512MSH |
1 min. 42 sec. |
3 min. 17 sec. |
3 min. 48 sec. |
6 min. 59 sec. |
5 min. 17 sec. |
9 min. 19 sec. |
*For shooting 1280x720 movies, a memory card with a nominal transfer speed of 20MB/sec. or faster is recommended. |
Playback Modes File
|
Still Image: Single, Magnification (approx. 2x-10x), Jump, Auto Rotate, Rotate, Resume, My Category, Histogram, Index (9 thumbnails), Sound Memos, Sound Recorder, Slide Show, Red-eye Correction
Movie: Normal Playback, Special Playback, Editing, Auto Rotate, Resume
|
Erase Modes
|
Still Image: single image, by date, by category, by folder, all images
Movie: part of movie, all of movie
|
Computer Interface
|
USB 2.0 Hi-Speed (mini-B jack)
|
Video Out
|
NTSC/PAL
|
Audio Out
|
Stereo
|
Other
|
Memory card slot; direct connection to Canon CP and SELPHY Compact Photo Printers, PIXMA Photo Printers and PictBridge-compatible printers via camera's USB 2.0 Hi-Speed cable
|
Power Source
|
1. Rechargeable Lithium Battery NB-4L
2. AC Adapter Kit ACK-DC10
|
Shooting Capacity
|
Still Image: approx. 160 shots (NB-4L/LCD on)*
|
Playback Time
|
Approx. 240 min. (NB-4L)*
* The above figures comply with CIPA testing standards and apply when a fully-charged battery is used.
|
Operating Temperature
|
32-104°F/0-40°C
|
Operating Humidity
|
10-90%
|
Dimensions (W x H x D)
|
3.50 x 2.36 x 1.14 in. / 88.8 x 59.9 x 29.0mm
|
Weight
|
Approx. 7.76 oz. / 220g (camera body only)
|
|
|
Note: Note: 25 display languages provided (English, German, French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish, Spanish, Simplified/Traditional Chinese, Japanese, Russian, Portuguese, Korean, Greek, Polish, Czech, Hungarian, Turkish, Thai, Arabic, Romanian, Ukrainian)
All data are based on Canon's Standard Test Method. Subject to change without notice.
